Key Commercial Data
| Orderkey | 2987901 |
|---|---|
| Packing unit | 10 pc |
| Minimum order quantity | 10 pc |
| Catalog page | Page 306 (C-5-2017) |
| GTIN | 4046356481038 |
| Weight per Piece (excluding packing) | 17.580 g |
| Custom tariff number | 85364900 |
| Country of origin | CN (China) |
Ambient conditions
| Ambient temperature (operation) | -40 °C … 70 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
Coil side
| Nominal input voltage UN | 120 V AC |
|---|---|
| Mains frequency | 50/60 Hz |
| Typical input current at UN | 7 mA |
| Typical response time | 3 ms … 12 ms (depending on phase relation) |
| Typical release time range | 2 ms … 8 ms (depending on phase relation) |
| Power dissipation for nominal condition | 0.84 W |
Contact side
| Contact type | 1 PDT |
|---|---|
| Type of switch contact | Single contact |
| Contact material | AgNi |
| Maximum switching voltage | 250 V AC/DC |
| Minimum switching voltage | 12 V (at 10 mA) |
| Min. switching current | 10 mA (at 12 V) |
| Maximum inrush current | 32 A (20 ms) |
| Limiting continuous current | 16 A |
| Interrupting rating (ohmic load) max. | 4000 VA (for 250 V AC) |
| Switching capacity | 2 A (at 24 V, DC13) |
| 3 A (at 24 V, AC15) | |
| 3 A (at 120 V, AC15) | |
| 3 A (at 240 V, AC15) | |
| Motor load according to UL 508 | 1/2 HP, 120 V AC (N/O contact) |
| 1 HP, 240 V AC (N/O contact) | |
| 1/3 HP, 120 V AC (N/C contact) | |
| 1/2 HP, 240 V AC (N/C contact) |
General
| Test voltage relay winding/relay contact | 5 kV AC (50 Hz, 1 min.) |
|---|---|
| Mechanical service life | 5x 106cycles |
| Service life, electrical | see diagram |
| Net weight (SAP) | 17.58 g |
