Key Commercial Data
| Orderkey | 2906990 |
|---|---|
| Packing unit | 1 pc |
| GTIN | 4055626171227 |
| Weight per Piece (excluding packing) | 604.300 g |
| Custom tariff number | 85371091 |
| Country of origin | CN (China) |
Dimensions
| Width | 35 mm |
|---|---|
| Height | 130 mm |
| Depth | 125 mm |
| Width with alternative assembly | 123 mm |
| Height with alternative assembly | 130 mm |
| Depth with alternative assembly | 37 mm |
Ambient conditions
| Degree of protection | IP20 |
|---|---|
| Ambient temperature (operation) | -25 °C … 70 °C (> 60 °C Derating: 2.5 %/K) |
| Ambient temperature (start-up type tested) | -40 °C |
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
| Max. permissible relative humidity (operation) | ≤ 95 % (at 25 °C, non-condensing) |
| Climatic class | 3K3 (EN 60721) |
| Degree of pollution | 2 |
| Installation height | ≤ 4000 m |
Input data
| Input voltage | 24 V DC |
|---|---|
| Input voltage range | 18 V DC … 30 V DC |
| Electric strength, max. | 35 V DC (Protected against polarity reversal) |
| Internal input fuse | no |
| Inrush surge current | ≤ 7 A (≤ 4 ms) |
| Reverse polarity protection | yes |
| Fixed connect threshold | 22 V DC |
| Switch-on time | max. 3 s |
| Voltage drop, input/output | 0.3 V DC |
Output data (general)
| Short-circuit-proof | yes |
|---|---|
| No-load proof | yes |
| Switch-over time | 0 ms |
| UPS connection in parallel | no |
| UPS connection in series | no |
| Energy storage device connection in parallel | Yes, 5 (observe line protection) |
| Energy storage device connection in series | no |
| Efficiency | typ. 98 % |
Output data (mains operation)
| Output voltage range | 18 V DC … 30 V DC (UOut= UIn– 0.3 V DC) |
|---|---|
| 18 V DC … 32 V DC (UOut= UIn– 0.3 V DC) | |
| Static Boost (IStat.Boost) | 6.25 A |
| Dynamic Boost (IDyn.Boost) | 10 A (5 s) |
| Selective Fuse Breaking (ISFB) | 30 A (15 ms) |
