Key Commercial Data
| Orderkey | 2320283 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 281 (C-4-2017) |
| GTIN | 4055626244563 |
| Weight per Piece (excluding packing) | 5,530.000 g |
| Custom tariff number | 85371091 |
| Country of origin | DE (Germany) |
Ambient conditions
| Degree of protection | IP20 |
|---|---|
| Ambient temperature (operation) | -25 °C … 60 °C (> 50 °C Derating: 2.5 %/K) |
| Ambient temperature (storage/transport) | -40 °C … 85 °C (with charged energy storage device) |
| Max. permissible relative humidity (operation) | ≤ 95 % |
| Climatic class | 3K3 (EN 60721) |
| Degree of pollution | 2 |
| Installation height | ≤ 3000 m (> 2000 m, observe derating) |
Input data
| Nominal input voltage | 100 V AC -10 % / +20 % |
|---|---|
| 110 V AC -10 % / +20 % | |
| 120 V AC -10 % / +20 % | |
| 130 V AC -10 % / +20 % | |
| 200 V AC -20 % / +20 % | |
| 210 V AC -20 % / +20 % | |
| 220 V AC -20 % / +20 % | |
| 230 V AC -20 % / +15 % | |
| 240 V AC -20 % / +10 % | |
| Input voltage range | 90 V AC … 264 V AC |
| AC frequency range | 45 Hz … 65 Hz |
| Buffer period | 1 h (38 AH) |
| Permissible backup fuse | B16 230 V AC |
| Power factor (cos phi) | 0.9 |
Output data
| Nominal output voltage | 100 V AC |
|---|---|
| 110 V AC | |
| 120 V AC | |
| 130 V AC | |
| 200 V AC | |
| 210 V AC | |
| 220 V AC | |
| 230 V AC | |
| 240 V AC | |
| Nominal output current (IN) | 7.8 A (100 V AC) |
| 8.1 A (110 V AC) | |
| 8.3 A (120 V AC) | |
| 7.7 A (130 V AC) | |
| 5 A (200 V AC) | |
| 4.8 A (210 V AC) | |
| 4.5 A (220 V AC) | |
| 4.3 A (230 V AC) | |
| 4.2 A (240 V AC) | |
| POWER BOOST (IBoost) | 13 A (120 V AC) |
| 7 A (230 V AC) | |
| Derating | > 50 °C … 60 °C (2.5%/K) |
| Connection in parallel | Yes, 2 |
| Connection in series | No |
| Maximum power dissipation in no-load condition | typ. 17 W (120 V AC) |
| typ. 25 W (230 V AC) |
General
| Net weight | 5 kg |
|---|---|
| Efficiency | > 92 % (120 V AC) |
| > 94 % (230 V AC) | |
| Protection class | I |
| Degree of protection | IP20 |
| MTBF (IEC 61709, SN 29500) | 217546 h (230 V AC, at 40 °C) |
