Key Commercial Data
| Orderkey | 3260069 |
|---|---|
| Packing unit | 10 pc |
| Minimum order quantity | 10 pc |
| Note | Made to Order (non-returnable) |
| GTIN | 4055626230535 |
| Weight per Piece (excluding packing) | 157.290 g |
| Custom tariff number | 85369010 |
| Country of origin | PL (Poland) |
General
| Number of positions | 1 |
|---|---|
| Number of levels | 1 |
| Number of connections | 2 |
| Potentials | 1 |
| Nominal cross section | 50 mm² |
| Color | orange |
| Insulating material | PA |
| Flammability rating according to UL 94 | V0 |
| Rated surge voltage | 8 kV |
| Degree of pollution | 3 |
| Overvoltage category | III |
| Insulating material group | I |
| Maximum power dissipation for nominal condition | 4.73 W |
| Maximum load current | 150 A (with 70 mm² conductor cross section) |
| Nominal current IN | 150 A |
| Nominal voltage UN | 1000 V AC |
| 1500 V DC | |
| Open side panel | No |
Connection data
| Connection method | Power-Turn connection |
|---|---|
| Connection in acc. with standard | IEC 60947-7-1 |
| Conductor cross section solid min. | 10 mm² |
| Conductor cross section solid max. | 70 mm² |
| Conductor cross section AWG min. | 8 |
| Conductor cross section AWG max. | 2/0 |
| Conductor cross section flexible min. | 10 mm² |
| Conductor cross section flexible max. | 70 mm² |
| Min. AWG conductor cross section, flexible | 8 |
| Max. AWG conductor cross section, flexible | 2/0 |
| Conductor cross section flexible, with ferrule without plastic sleeve min. | 10 mm² |
| Conductor cross section flexible, with ferrule without plastic sleeve max. | 50 mm² |
| Conductor cross section flexible, with ferrule with plastic sleeve min. | 10 mm² |
| Conductor cross section flexible, with ferrule with plastic sleeve max. | 50 mm² |
| Cross section with insertion bridge solid min. | 10 mm² |
| Cross section with insertion bridge, solid max. | 50 mm² |
| Cross section with insertion bridge stranded min. | 10 mm² |
| Cross section with insertion bridge, stranded max. | 50 mm² |
| Cross section with insertion bridge stranded, with ferrule without plastic sleeve min. | 10 mm² |
| Cross section with insertion bridge stranded, with ferrule without plastic sleeve max. | 50 mm² |
| Cross section with insertion bridge stranded, with ferrule without plastic sleeve min. | 10 mm² |
| Cross section with insertion bridge stranded, with ferrule with plastic sleeve max. | 50 mm² |
| Stripping length | 30 mm … 32 mm |
| Internal cylindrical gage | A10 |
Standards and Regulations
| Connection in acc. with standard | IEC 60947-7-1 |
|---|---|
| Flammability rating according to UL 94 | V0 |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
