Key Commercial Data
| Orderkey | 2800989 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 72 (C-6-2013) |
| GTIN | 4046356665971 |
| Weight per Piece (excluding packing) | 50.100 g |
| Custom tariff number | 85363010 |
| Country of origin | DE (Germany) |
Dimensions
| Height | 46.6 mm |
|---|---|
| Width | 17.7 mm |
| Depth | 45 mm |
| Horizontal pitch | 1 Div. |
| Complete module height | 91.1 mm |
| Complete module width | 17.7 mm |
| Complete module depth | 77.5 mm |
Ambient conditions
| Ambient temperature (operation) | -40 °C … 70 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
| Altitude | max. 4000 m |
| Degree of protection | IP20 |
General
| Housing material | PA 6.6 |
|---|---|
| Flammability rating according to UL 94 | V0 |
| Color | jet black RAL 9005 |
| Type | Male |
Protective circuit
| Nominal voltage UN | 24 V DC |
|---|---|
| Rated current | 130 mA (at 24 V DC, depending on the number of surge protection modules connected) |
| max. 160 mA (at 20 V DC) | |
| Surge protection fault message | Optical, multi-stage |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
