Key Commercial Data
| Orderkey | 2986012 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 293 (C-6-2017) |
| GTIN | 4046356346979 |
| Weight per Piece (excluding packing) | 154.000 g |
| Custom tariff number | 85371098 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -20 °C … 55 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
| Max. permissible relative humidity (operation) | 75 % (On average, 85 % occasionally) |
| Max. permissible humidity (storage/transport) | 75 % (On average, 85 % occasionally) |
| Air pressure (operation) | 70 kPa … 108 kPa (up to 3000 m above sea level) |
| Air pressure (storage/transport) | 66 kPa … 108 kPa (up to 3500 m above sea level) |
| Maximum altitude | max. 2000 m (See Appendix “Using PSR-TRISAFE modules at altitudes greater than 2000 m above sea level”) |
Power supply
| Rated control circuit supply voltage US | 24 V DC (A1/A2) |
|---|---|
| 18 V DC … 30 V DC (Incl. all tolerances, incl. residual ripple) | |
| Rated control supply current IS | typ. 110 mA |
| Limiting continuous current | max. 6 A (For looped-through current paths A1/A1 and A2/A2) |
| Filter time | typ. 20 ms (Load-dependent, in the event of voltage dips at US) |
| Status display | 3x LED green, 1x LED red |
| Protective circuit | Yes, within the scope of the operating voltage limits |
Digital inputs
| Description of the input | Digital, type HTL |
|---|---|
| Number of inputs | 10 (Two-channel, up to SIL 3) |
| 20 (Single-channel, up to SIL 2) | |
| Input voltage range “0” signal | 0 V DC … 5 V DC (for safe Off) |
| Input voltage range “1” signal | 11 V DC … 30 V DC |
| Current consumption | typ. 4 mA |
| Cable length | max. 2000 m |
| Status display | 20 x LED green (1 LED per input) |
