Key Commercial Data
| Orderkey | 2981936 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 265 (C-6-2017) |
| GTIN | 4046356326001 |
| Weight per Piece (excluding packing) | 160.000 g |
| Custom tariff number | 85364190 |
| Country of origin | DE (Germany) |
Ambient conditions
| Ambient temperature (operation) | -20 °C … 55 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 70 °C |
| Degree of protection | IP20 |
Supply
| Nominal input voltage UN | 24 V DC (from PSR) |
|---|---|
| Input voltage range in reference to UN | 0.85 … 1.1 |
General
| Status display | Green LED |
|---|---|
| Max. permissible current | 100 mA (per signal output) |
| Max. permissible total current | 100 mA (alarm outputs) |
| Nominal operating mode | 100% operating factor |
| Mounting position | any |
| Assembly instructions | In rows with zero spacing |
| Designation | Air clearances and creepage distances between the power circuits |
| Standards/regulations | DIN EN 50178 |
| Rated insulation voltage | 50 V DC |
| Degree of pollution | 2 |
| Overvoltage category | III |
Connection data
| Connection method | Screw connection |
|---|---|
| pluggable | Yes |
| Conductor cross section solid min. | 0.2 mm² |
| Conductor cross section solid max. | 2.5 mm² |
| Conductor cross section flexible min. | 0.2 mm² |
| Conductor cross section flexible max. | 2.5 mm² |
| Conductor cross section AWG min. | 24 |
| Conductor cross section AWG max. | 12 |
| Stripping length | 7 mm |
| Screw thread | M3 |
