Key Commercial Data
| Orderkey | 2702355 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 276 (C-6-2017) |
| GTIN | 4055626133201 |
| Weight per Piece (excluding packing) | 150.100 g |
| Custom tariff number | 85389091 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -20 °C … 55 °C (observe derating) |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
| Max. permissible relative humidity (operation) | 75 % (on average, 85% infrequently, non-condensing) |
| Max. permissible humidity (storage/transport) | 75 % (on average, 85% infrequently, non-condensing) |
| Maximum altitude | max. 2000 m (Above sea level) |
Power supply
| Rated control circuit supply voltage US | 24 V DC -15 % / +10 % |
|---|---|
| Rated control supply current IS | typ. 50 mA |
| Power consumption at US | typ. 1.2 W |
| Inrush current | 5.6 A (Δt = 400 µs at Us) |
| Filter time | 1 ms (at A1 in the event of voltage dips at Us) |
| Protective circuit | Surge protection Suppressor diode |
| Protection against polarity reversal for rated control circuit supply voltage |
Measuring inputs
| Current consumption | max. 0.35 mA (at L1/L2/L3) |
|---|---|
| Voltage input signal | max. 690 V AC/DC (at L1/L2/L3) |
| Limit frequency | max. 3 kHz (At voltages > 2 VRMS) |
