Key Commercial Data
| Orderkey | 2702976 |
|---|---|
| Packing unit | 1 pc |
| GTIN | 4055626447032 |
| Weight per Piece (excluding packing) | 41.300 g |
| Custom tariff number | 85365019 |
| Country of origin | DE (Germany) |
Ambient conditions
| Ambient temperature (operation) | -25 °C … 55 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 70 °C |
Power supply
| Supply voltage | 24 V DC ±15 % (PELV, controlled, residual ripple |
|---|---|
| Current consumption | max. 40 mA |
| Protection | min. 0.25 A (to be performed externally) |
| max. 8 A (to be performed externally) |
Alarm outputs
| Designation | DGN |
|---|---|
| Output description | p-wired |
| Number of outputs | 1 |
| Short-circuit-proof | yes |
| Output voltage | min. (UB– 1.5 V (HIGH)) |
| max. (UB(HIGH)) | |
| min. 0 V DC (LOW) | |
| max. 1 V DC (LOW) | |
| Current IDGN | min. 1 mA |
Safety outputs
| Designation | FO1A, FO1B |
|---|---|
| Output description | Semiconductor outputs, p-wired |
| Number of outputs | 2 |
| Output voltage | min. (UB– 1.5 V (HIGH FO1A, FO1B)) |
| max. (UB(HIGH FO1A, FO1B)) | |
| min. 0 V DC (LOW FO1A/FO1B) | |
| max. 1 V DC (LOW FO1A/FO1B) | |
| Switching current | min. 1 mA (per safety output) |
| max. 150 mA (per safety output) | |
| Short-circuit-proof | yes |
| Utilization category in accordance with IEC 60947-5-2 | 150 mA (24 V (DC13)) |
| Note on protection circuit | NOTE: Protect the outputs under inductive loads with a freewheeling diode. |
| Residual current | ≤ 0.25 mA |
