Key Commercial Data
| Orderkey | 2400018 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 215 (C-5-2017) |
| GTIN | 4055626016429 |
| Weight per Piece (excluding packing) | 475.000 g |
| Custom tariff number | 84719000 |
| Country of origin | NL (Netherlands) |
Ambient conditions
| Degree of protection | IP20 |
|---|---|
| Ambient temperature (operation) | -20 °C … 65 °C |
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
| Permissible humidity (operation) | 10 % … 95 % (according to DIN EN 61131-2) |
| Permissible humidity (storage/transport) | 10 % … 95 % (according to DIN EN 61131-2) |
| Air pressure (operation) | 70 kPa … 106 kPa (up to 3000 m above sea level) |
| Air pressure (storage/transport) | 70 kPa … 106 kPa (up to 3000 m above sea level) |
| Shock | 25g, Criterion 1, according to IEC 60068-2-27 |
| Vibration (operation) | 5g |
Standards and Regulations
| Electromagnetic compatibility | Conformance with EMC Directive 2014/30/EU |
|---|---|
| Interference emission | Noise emission test as per EN 61000-6-4 EN 55011 (emitted interference) Class A |
| Noise immunity | Noise immunity test in accordance with EN 61000-6-2 Electromagnetic fields EN 61000-4-3/IEC 61000-4-3 EN 61000-4-3 (radiated noise immunity) Criterion A, 10 V/m |
| Immunity to surge | Noise immunity test in accordance with EN 61000-6-2 Transient overvoltage (surge) EN 61000-4-5/IEC 61000-4-5 EN 61000-4-5 (surge) Criterion B |
| Immunity to burst | Noise immunity test in accordance with EN 61000-6-2 Fast transients (burst) EN 61000-4-4/IEC 61000-4-4 EN 61000-4-4 (EFT burst) Criterion B; Supply lines: 2 kV; Signal/data lines: 2 kV |
| Immunity to ESD | Noise immunity test in accordance with EN 61000-6-2 Electrostatic discharge (ESD) EN 61000-4-2/IEC 61000-4-2 EN 61000-4-2 (ESD) Criterion B, 6 kV contact discharge, 8 kV air discharge |
| Immunity to conducted interference | Noise immunity test in accordance with EN 61000-6-2 Conducted interference EN 61000-4-6/IEC 61000-4-6 EN 61000-4-6 (line noise immunity) Criterion A; Test voltage 10 V |
| Noise emission | EN 61000-6-4 |
| Vibration (storage/transport) | 5g |
| Shock | 25g, Criterion 1, according to IEC 60068-2-27 |
| Vibration (operation) | 5g |
Data interfaces
| Interface | RS-232 |
|---|---|
| RS-232/-485 | |
| Serial | |
| Ethernet | |
| Connection method | RJ45 |
| Interface description | GSM / GPRS |
| Minimum frequency | 850 MHz |
| Max. frequency | 1900 MHz |
| Number | 1 |
| Connection method | SMA (female) |
| Resistance | 50 Ω |
| SIM Interface | 1.8 volt and 3 volt SIM card |
Power supply
| Typical current consumption | 5 mA |
|---|---|
| Max. current consumption | 100 mA |
| Supply voltage | 24 V DC |
| Supply voltage range | 10 V DC … 30 V DC |
| Power dissipation | max. 0.12 W |
| Battery capacity | 235 mAh |
| Battery voltage | 3 V DC |
| Service life of battery | 6 years |
