Key Commercial Data
| Orderkey | 2708083 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 327 (C-6-2017) |
| GTIN | 4017918943202 |
| Weight per Piece (excluding packing) | 198.200 g |
| Custom tariff number | 85176200 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -20 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
| Permissible humidity (operation) | 30 % … 95 % (non-condensing) |
| Altitude | 5000 m (For restrictions see manufacturer’s declaration) |
| Degree of protection | IP20 |
| Noise immunity | EN 61000-6-2 |
Serial interface
| Interface 1 | CAN interface, in accordance with ISO/IS 11898 for DeviceNet, CAN, CANopen |
|---|---|
| Connection method | Pluggable screw connection |
| File format/coding | Bit stuffing, NRZ |
| Transmission medium | Copper |
| Transmission length | ≤ 5000 m (Dependent on the data rate and the protocol used) |
| Termination resistor | 120 Ω (Can be connected) |
| Serial transmission speed | ≤ 800 kbps |
Optical interface FO
| Transmit capacity, minimum | -17.9 dBm (50/125 µm) |
|---|---|
| -14.1 dBm (62,5/125 µm) | |
| -5.1 dBm (200/230 µm) | |
| Minimum receiver sensitivity | -32.5 dBm (50/125 µm) |
| -32.5 dBm (62,5/125 µm) | |
| -32.1 dBm (200/230 µm) | |
| Wavelength | 850 nm |
| Transmission length incl. 3 dB system reserve | 2800 m (with F-K 200/230 8 dB/km with quick mounting connector) |
| 4800 m (with F-G 50/125 2.5 dB/km) | |
| 4200 m (with F-G 62,5/125 3.0 dB/km) | |
| Transmission medium | PCF fiber |
| Multi-mode fiberglass | |
| Connection method | B-FOC (ST®) |
