Key Commercial Data
| Orderkey | 1621325 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 76 (NTK-2014) |
| GTIN | 4046356914727 |
| Weight per Piece (excluding packing) | 94.800 g |
| Custom tariff number | 85366990 |
| Country of origin | PL (Poland) |
General data
| Number of positions | 5 |
|---|---|
| Protection class | II |
| Color | black |
| Locking type | Snap-in locking |
| Insertion/withdrawal cycles | 2000 () |
| Pull-out-force | 175 N ± 50 N |
| Insertion force | 40 N ±10 N |
| Degree of protection (when plugged in) | IP66 / IP68 (2m / 24h) / IP69K |
Connection data
| Rated current | 30 A (with 6 mm² conductor cross section) |
|---|---|
| Rated voltage (III/2) | 690 V |
| Conductor cross section flexible min. | 4 mm² |
| Conductor cross section flexible max. | 6 mm² |
| Conductor cross section solid min. | 1.5 mm² |
| Conductor cross section solid max. | 6 mm² |
| Stripping length | 12 mm |
| Torque | 1 Nm |
| Type of contact | Socket |
| Stripping length of the sheath | 50 mm |
Material data
| Contact material | Cu |
|---|---|
| Contact surface material | silver-plated |
| Contact carrier material | PPE |
| Material of grip body | PPE |
| Flammability rating according to UL 94 | V0 |
Environmental Product Compliance
| REACh SVHC | Lead 7439-92-1 |
|---|---|
| China RoHS | Environmentally Friendly Use Period = 50 |
| For details about hazardous substances go to tab “Downloads”, Category “Manufacturer’s declaration” |
