Key Commercial Data
| Orderkey | 2833602 |
|---|---|
| Packing unit | 10 pc |
| Minimum order quantity | 10 pc |
| Catalog page | Page 388 (C-7-2015) |
| GTIN | 4017918933821 |
| Weight per Piece (excluding packing) | 60.570 g |
| Custom tariff number | 85366990 |
| Country of origin | CN (China) |
Ambient conditions
| Ambient temperature (operation) | -40 °C … 85 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
Connection data, input side
| Connection name | Input side |
|---|---|
| Connection method | Screw connection |
| Stripping length | 10 mm |
| Screw thread | M3 |
| Conductor cross section solid | 0.2 mm² … 2.5 mm² |
| 0.2 mm² … 2.5 mm² (2 conductors with the same cross-section) | |
| Conductor cross section flexible | 0.2 mm² … 2.5 mm² |
| 0.2 mm² … 2.5 mm² (2 conductors with the same cross-section) | |
| Conductor cross section AWG | 26 … 14 |
| 26 … 14 (2 conductors with the same cross-section) |
Connection data, output side
| Connection name | Output side |
|---|---|
| Connection method | Screw connection |
| Stripping length | 10 mm |
| Screw thread | M3 |
| Conductor cross section solid | 0.2 mm² … 2.5 mm² |
| 0.2 mm² … 2.5 mm² (2 conductors with the same cross-section) | |
| Conductor cross section flexible | 0.2 mm² … 2.5 mm² |
| 0.2 mm² … 2.5 mm² (2 conductors with the same cross-section) | |
| Conductor cross section AWG | 26 … 14 |
| 26 … 14 (2 conductors with the same cross-section) |
