Key Commercial Data
| Orderkey | 2834698 |
|---|---|
| Packing unit | 5 pc |
| Minimum order quantity | 5 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 395 (C-7-2013) |
| GTIN | 4017918996260 |
| Weight per Piece (excluding packing) | 125.000 g |
| Custom tariff number | 85364900 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -25 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -25 °C … 70 °C |
Coil side
| Nominal input voltage UN | 24 V AC |
|---|---|
| Typical input current at UN | 54 mA (at 50 Hz) |
| 46 mA (At 60 Hz) | |
| Typical response time | 4 ms … 10 ms |
| Typical release time range | 3 ms … 12 ms |
| Protective circuit | Varistor |
| Operating voltage display | LED red |
| Power dissipation for nominal condition | 1.3 W |
Contact side
| Contact type | 2 PDT |
|---|---|
| Type of switch contact | Single contact |
| Contact material | Ag |
| Maximum switching voltage | 250 V AC/DC |
| Minimum switching voltage | 5 V |
| Min. switching current | 1 mA |
| Maximum inrush current | 20 A (15 ms) |
| Limiting continuous current | 10 A |
| Interrupting rating (ohmic load) max. | 240 W (at 24 V DC) |
| 160 W (at 48 V DC) | |
| 110 W (at 60 V DC) | |
| 72 W (at 110 V DC) | |
| 130 W (at 220 V DC) | |
| 2500 VA (for 250 V AC) |
