Key Commercial Data
| Orderkey | 2834724 |
|---|---|
| Packing unit | 5 pc |
| Minimum order quantity | 5 pc |
| Catalog page | Page 397 (C-7-2015) |
| GTIN | 4046356044554 |
| Weight per Piece (excluding packing) | 115.270 g |
| Custom tariff number | 85364900 |
| Country of origin | JP (Japan) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -25 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -25 °C … 70 °C |
Coil side
| Nominal input voltage UN | 24 V DC |
|---|---|
| Input voltage range in reference to UN | see diagram |
| Typical input current at UN | 38 mA |
| Typical response time | 13 ms |
| Typical release time | 14 ms |
| Protective circuit | Damping diode |
| Operating voltage display | Green LED |
| Power dissipation for nominal condition | 0.91 W |
Contact side
| Contact type | 4 PDTs |
|---|---|
| Type of switch contact | Single contact |
| Contact material | AgNi, hard gold-plated |
| Maximum switching voltage | 250 V AC/DC |
| Minimum switching voltage | 1 V |
| Min. switching current | 1 mA |
| Maximum inrush current | 12 A (15 ms) |
| Limiting continuous current | 5 A |
| Interrupting rating (ohmic load) max. | 1250 VA (for 250 V AC) |
| 120 W (at 24 V DC) | |
| 110 W (at 48 V DC) | |
| 78 W (at 60 V DC) | |
| 55 W (at 110 V DC) | |
| 77 W (at 220 V DC) |
