Key Commercial Data
| Orderkey | 2834588 |
|---|---|
| Packing unit | 5 pc |
| Minimum order quantity | 5 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 393 (C-7-2013) |
| GTIN | 4046356044479 |
| Weight per Piece (excluding packing) | 65.770 g |
| Custom tariff number | 85364900 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -25 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -25 °C … 85 °C |
Coil side
| Nominal input voltage UN | 120 V AC |
|---|---|
| Typical input current at UN | 9 mA (at 50 Hz) |
| 7 mA (At 60 Hz) | |
| Typical response time | 3 ms … 12 ms |
| Typical release time range | 1.5 ms … 16 ms |
| Protective circuit | Varistor |
| Operating voltage display | Yellow LED |
| Power dissipation for nominal condition | 1.08 W |
Contact side
| Contact type | 2 PDT |
|---|---|
| Type of switch contact | Single contact |
| Contact material | AgNi |
| Maximum switching voltage | 250 V AC/DC |
| Minimum switching voltage | 5 V (at 10 mA) |
| Min. switching current | 10 mA (At 5 V) |
| Maximum inrush current | 15 A (300 ms) |
| Limiting continuous current | 8 A |
| Interrupting rating (ohmic load) max. | 2000 W (for 250 V AC) |
| 44 W (at 110 V DC) | |
| 60 W (at 220 V DC) | |
| 190 W (at 24 V DC) | |
| at 440 V AC | |
| 85 W (at 48 V DC) | |
| 60 W (at 60 V DC) | |
| Switching capacity | 2 A (at 24 V, DC13) |
| 0.2 A (at 250 V, DC13) | |
| 3 A (at 24 V, AC15) | |
| 3 A (at 120 V, AC15) | |
| 3 A (at 250 V, AC15) |
