Key Commercial Data
| Orderkey | 2702933 |
|---|---|
| Packing unit | 1 pc |
| GTIN | 4055626443744 |
| Weight per Piece (excluding packing) | 470.000 g |
| Custom tariff number | 94054099 |
| Country of origin | DE (Germany) |
Dimensions
| Dimensional drawing | |
|---|---|
| Width | 40 mm |
| Height | 30 mm |
| Length | 190 mm |
| Note on dimensions | Length without M12 flush-type connector |
Ambient conditions
| Ambient temperature (operation) | 0 °C … 50 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 75 °C |
| Permissible humidity (operation) | 95 % |
| Permissible humidity (storage/transport) | 95 % (non-condensing) |
| Air pressure (operation) | 69 kPa … 102 kPa |
| Air pressure (storage/transport) | 69 kPa … 102 kPa |
| Degree of protection | IP67 |
General
| Note | The PLD M-ME MC/D40 mounting holder (Order No. 2702491) or the PLD M-ME MB/D40 mounting bracket (Order No. 2702527) is required in order to mount the light. |
|---|---|
| Net weight | 470 g |
| Mounting type | Screw mounting |
| Assembly instructions | Mounting with mounting holders or mounting brackets, please observe the notes in the package slip. |
Power supply for module electronics
| Connection technology | M12 connector |
|---|---|
| Connection method | M12 connector, (A-coded) |
| Number of positions | 4 |
| Permissible conductor cross section | min. 0.34 mm² |
| Supply voltage | 24 V DC |
| Supply voltage range | 20 V DC … 28 V DC |
| Current consumption | typ. 0.21 A (at 24 V DC) |
| Power consumption | approx. 5 W (at 24 V DC) |
| Type of protection | Surge protection |
| Reverse polarity protection |
