Key Commercial Data
| Orderkey | 2907446 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 429 (C-5-2017) |
| GTIN | 4055626218168 |
| Weight per Piece (excluding packing) | 136.000 g |
| Custom tariff number | 85371098 |
| Country of origin | DE (Germany) |
Power supply
| Supply voltage | 24 V DC |
|---|---|
| Supply voltage range | 19.2 V DC … 26.4 V DC |
| Typical input current at UN | 40 mA |
| Maximum input current at UN | 160 mA |
| Protective circuit | Reverse polarity protection |
| Surge protection | |
| Status display | Green LED |
Input data (digital)
| Number of inputs | 8 (2 configurable as analog) |
|---|---|
| Description of the input | EN 61131-2, type 3 |
| Input voltage | 24 V DC |
| Signal level “0” signal | < 5 V |
| Signal level “1” signal | > 11 V |
| Input current “0” signal | < 1 mA |
| Input current “1” signal | typ. 2.5 mA |
| Status display | Yellow LED |
Input data (analog)
| Number of inputs | 2 (IN6 and IN7 are configurable as analog) |
|---|---|
| Input voltage range | 0 V … 10 V |
| Input resistance | > 3.5 kΩ |
Input data (PLC-INTERFACE)
| Number of inputs | ≤ 8 |
|---|---|
| Description of the input | technical data depends on the PLC-INTERFACE terminal block used |
| Input voltage | 19 V DC |
| Typical current consumption | 4 mA |
| Input resistance | < 100 mΩ |
