Key Commercial Data
| Orderkey | 2906920 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 431 (C-5-2017) |
| GTIN | 4055626155517 |
| Weight per Piece (excluding packing) | 50.300 g |
| Custom tariff number | 85389099 |
| Country of origin | DE (Germany) |
Ambient conditions
| Ambient temperature (operation) | -20 °C … 50 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
Supply
| Rated control circuit supply voltage US | 24 V DC |
|---|---|
| Rated control supply voltage range with reference to US | 0.8 … 1.1 |
| Rated control supply current IS | ≤ 28 mA |
| Type of protection | Reverse polarity protection |
| Surge protection | |
| Operating voltage display | Green LED |
| Indication | Red LED |
Output data
| Output name | Analog voltage output |
|---|---|
| Voltage output signal | 0 V … 10 V |
| 2 V … 10 V | |
| Maximum output voltage | 12.3 V |
| Ripple | < 20 mVPP |
| Load/output load voltage output | 10 kΩ |
| Output protection | |
| Surge voltage protection | > 33 V |
| Maximum transmission error | 1 % |
| Output name | Analog output for current |
| Current output signal | 0 mA … 20 mA |
| 4 mA … 20 mA | |
| Maximum output current | 24.6 mA |
| Load/output load current output | 500 Ω (20 mA) |
| Output protection | |
| Surge voltage protection | > 33 V |
| Maximum transmission error | 1 % |
