Key Commercial Data
| Orderkey | 2987309 |
|---|---|
| Packing unit | 10 pc |
| Catalog page | Page 402 (C-5-2017) |
| GTIN | 4046356451215 |
| Weight per Piece (excluding packing) | 34.000 g |
| Custom tariff number | 85364190 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -20 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 60 °C |
Coil side
| Nominal input voltage UN | 24 V DC |
|---|---|
| Typical input current at UN | 7 mA |
| Typical response time | 4 ms |
| Typical release time | 6 ms |
| Protective circuit | Reverse polarity protection Polarity protection diode |
| Free-wheeling diode Damping diode | |
| Operating voltage display | Yellow LED |
| Power dissipation for nominal condition | 0.17 W |
Contact side
| Contact type | 2 N/O contacts (2 relays with 1 N/O contact) |
|---|---|
| Type of switch contact | Single contact |
| Note regarding the switch contact | 2x |
| Contact material | AgNi |
| Maximum switching voltage | 250 V AC |
| 30 V DC | |
| Minimum switching voltage | 24 V AC/DC |
| Min. switching current | 5 mA |
| Limiting continuous current | 3.5 A |
| Interrupting rating (ohmic load) max. | 84 W (at 24 V DC) |
| 24 W (at 48 V DC) | |
| 24 W (at 60 V DC) | |
| 31 W (at 110 V DC) | |
| 46 W (at 220 V DC) | |
| 875 VA (for 250 V AC) |
