Key Commercial Data
| Orderkey | 2835367 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 338 (IF-2002) |
| GTIN | 4017918178475 |
| Weight per Piece (excluding packing) | 77.710 g |
| Custom tariff number | 85437090 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -20 °C … 60 °C (vertical assembly) |
|---|---|
| -20 °C … 55 °C (horizontal assembly) | |
| Ambient temperature (storage/transport) | -40 °C … 80 °C |
| Permissible humidity (operation) | 5 % … 95 % (relative humidity, non-condensing) |
| Noise immunity | EN 61326:1997 |
Input data
| Control current circuit | Intrinsically safe |
|---|---|
| Available input sources | NAMUR proximity sensors |
| Floating switch contacts | |
| Switch contacts with resistance circuit | |
| Non-load voltage | 8.2 V DC ±10 % |
| Switching points (attenuated) | < 1.2 mA (attenuated in acc. with EN 60947-5-6) |
| Switching points (unattenuated) | > 2.1 mA (non-attenuated in acc. with EN 60947-5-6) |
| Line error detection | Activated /deactivated via DIP switch |
Output data
| Switching output | Relay output |
|---|---|
| Configurable/programmable | Switching behavior can be inverted via DIP switch |
| Contact type | N/C contact |
| Contact material | AgSnO, hard gold-plated |
| Limiting continuous current | 1 A (30 V DC) |
| 0.5 A (125 V AC) | |
| Min. contact current | 1 mA |
| Mechanical service life | 107cycles |
| Service life, electrical | 2x 105cycles (at full load) |
