Key Commercial Data
| Orderkey | 2982650 |
|---|---|
| Packing unit | 10 pc |
| Catalog page | Page 559 (C-7-2013) |
| GTIN | 4046356131667 |
| Weight per Piece (excluding packing) | 24.700 g |
| Custom tariff number | 85362010 |
| Country of origin | CN (China) |
Ambient conditions
| Ambient temperature (operation) | -20 °C … 70 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
Input data
| Nominal input voltage UN | 24 V DC |
|---|---|
| Input voltage range | 4 V DC … 32 V DC |
| Switching threshold “0” signal, voltage | < 1.2 V DC |
| Switching threshold “1” signal voltage | > 3.5 V DC |
| Typical input current at UN | 10 mA |
| Typical response time | ms (maximum ½ periods) |
| Typical turn-off time | ms (maximum ½ periods) |
| Transmission frequency | 25 Hz |
Output data
| Output voltage range | 12 V AC … 530 V AC (45/65 Hz) |
|---|---|
| Limiting continuous current | 5 A (see derating curve) |
| Min. load current | 20 mA |
| Leakage current | < 1 mA |
| Surge current | 80 A (tp = 20 ms) |
| Max. load value | 50 A2s |
| Peak offstate voltage | 1000 V (Periodic peak reverse voltage) |
| Voltage drop at max. limiting continuous current | 1.2 V |
| Output circuit | 2-conductor |
General
| Test voltage input/output | 4 kV (50 Hz, 1 min.) |
|---|---|
| Mounting position | any |
| Assembly instructions | Can be aligned with > 20 mm spacing |
| Operating mode | 100% operating factor |
| Standards/regulations | EN 61000-4-2 |
| EN 61000-4-3 | |
| EN 61000-4-4 | |
| EN 61000-4-5 | |
| EN 61000-4-6 | |
| EN 55011 |
