Key Commercial Data
| Orderkey | 2982634 |
|---|---|
| Packing unit | 10 pc |
| Catalog page | Page 558 (C-7-2013) |
| GTIN | 4046356131988 |
| Weight per Piece (excluding packing) | 23.000 g |
| Custom tariff number | 85362010 |
| Country of origin | CN (China) |
Ambient conditions
| Ambient temperature (operation) | -20 °C … 80 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 80 °C |
Input data
| Nominal input voltage UN | 24 V DC |
|---|---|
| Input voltage range | 4.25 V DC … 32 V DC |
| Switching threshold “0” signal, voltage | < 1 V DC |
| Switching threshold “1” signal voltage | > 3.3 V DC |
| Typical input current at UN | 15 mA |
| Typical response time | < 100 µs |
| Typical turn-off time | < 250 µs |
| Transmission frequency | 100 Hz |
Output data
| Output voltage range | 1 V DC … 350 V DC |
|---|---|
| Limiting continuous current | 1 A (see derating curve) |
| Min. load current | 1 mA |
| Leakage current | 100 µA |
| Surge current | 20 A (tp= 1 s) |
| Voltage drop at max. limiting continuous current | 0.5 V |
| Output circuit | 2-conductor |
| Type of protection | Reverse polarity protection |
| Protective circuit/component | Polarity protection diode |
General
| Test voltage input/output | 4 kV (50 Hz, 1 min.) |
|---|---|
| Mounting position | any |
| Assembly instructions | Can be aligned with > 9 mm spacing |
| Operating mode | 100% operating factor |
| Standards/regulations | EN 61000-4-2 |
| EN 61000-4-3 | |
| EN 61000-4-4 | |
| EN 55011 |
