Key Commercial Data
| Orderkey | 2701072 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 465 (C-8-2015) |
| GTIN | 4046356325332 |
| Weight per Piece (excluding packing) | 137.600 g |
| Custom tariff number | 85389099 |
| Country of origin | IN (India) |
Ambient conditions
| Degree of protection | IP20 |
|---|---|
| Ambient temperature (operation) | -25 °C … 60 °C |
| Ambient temperature (storage/transport) | -25 °C … 85 °C |
Supply
| Connection method | Screw connection |
|---|---|
| Supply voltage | 24 V DC |
| Supply current | typ. 50 mA |
| max. 90 mA |
Digital inputs
| Input name | Digital inputs |
|---|---|
| Description of the input | PNP/NPN |
| Connection method | Screw connection |
| Number of inputs | 6 |
| Typical response time | 60 µs (on) |
| 70 µs (OFF) | |
| Input voltage range “0” signal | 0 V DC … 5 V DC |
| Input voltage range “1” signal | 15 V DC … 30 V DC |
| Nominal input current at UIN | 5 mA DC (On) |
Digital outputs
| Output name | Digital outputs |
|---|---|
| Output description | PNP outputs |
| Connection method | Screw connection |
| Number of outputs | 4 |
| Type of protection | Short-circuit and overload protection |
| Maximum output current per channel | 500 mA |
| Maximum output current per module / terminal block | 2 A |
| Maximum output current per module | 2 A |
| Nominal load, inductive | 12 VA ((1.2H)) |
| Nominal load, lamp | 12 W |
| Nominal load, ohmic | 12 W |
