Key Commercial Data
| Orderkey | 2810078 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 96 (C-7-2015) |
| GTIN | 4046356043588 |
| Weight per Piece (excluding packing) | 79.600 g |
| Custom tariff number | 85437090 |
| Country of origin | DE (Germany) |
Ambient conditions
| Ambient temperature (operation) | -20 °C … 65 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
Input data
| Number of inputs | 1 |
|---|---|
| Configurable/programmable | Yes, unconfigured |
| Voltage input signal | 0 V … 24 V |
| 0 V … 30 V | |
| max. input voltage | 50 V DC |
| Input resistance of voltage input | approx. 125 kΩ (0 … 24 V) |
| approx. 155 kΩ (0 … 30 V) |
Output data
| Number of outputs | 1 |
|---|---|
| Configurable/programmable | Yes, unconfigured |
| Voltage output signal | 0 V … 10 V |
| 0 V … 5 V | |
| 1 V … 5 V | |
| 2 V … 10 V | |
| Current output signal | 0 mA … 20 mA |
| 4 mA … 20 mA | |
| Max. output voltage | ≤ 12.5 V |
| Max. output current | 28 mA |
| Short-circuit current | ≤ 22 mA |
| Load/output load voltage output | > 10 kΩ |
| Load/output load current output | < 500 Ω (at 20 mA) |
| Ripple | < 20 mVPP(at 500 Ω) |
| < 20 mVPP(at 10 kΩ) |
Power supply
| Nominal supply voltage | 24 V DC |
|---|---|
| Supply voltage range | 19.2 V DC … 30 V DC (The DIN rail bus connector (ME 6,2 TBUS-2 1,5/5-ST-3,81 GN, Order No. 2869728) can be used to bridge the supply voltage. It can be snapped onto a 35 mm DIN rail according to EN 60715)) |
| Max. current consumption | < 19 mA (at 24 V DC incl. load) |
| Power consumption | < 450 mW |
