Key Commercial Data
| Orderkey | 2864079 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 99 (C-7-2015) |
| GTIN | 4046356046428 |
| Weight per Piece (excluding packing) | 88.200 g |
| Custom tariff number | 85437090 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -20 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
Input data
| Description of the input | Current input (sensor circuit) |
|---|---|
| Number of inputs | 1 |
| Current input signal | 4 mA … 20 mA (repeater power supply and isolator operation) |
| 0 mA … 20 mA (isolator operation) | |
| Max. input current | 28 mA |
| Input resistance current input | approx. 50 Ω |
| Transmitter supply voltage | 16.5 V |
Output data
| Output name | Current output |
|---|---|
| Number of outputs | 1 |
| Current output signal | 4 mA … 20 mA (repeater power supply and isolator operation) |
| 0 mA … 20 mA (isolator operation) | |
| Max. output current | > 21 mA (22.5 mA, typical) |
| Load/output load current output | ≤ 500 Ω (I = 20 mA) |
| Ripple | < 20 mVrms(at 500 Ω) |
| Transmission Behavior | 1:1 to input signal |
