Key Commercial Data
| Orderkey | 2864370 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 104 (C-7-2015) |
| GTIN | 4046356046480 |
| Weight per Piece (excluding packing) | 74.400 g |
| Custom tariff number | 85437090 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -20 °C … 65 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
Input data
| Sensor types (RTD) that can be used | Pt 100 (IEC 60751/EN 60751) |
|---|---|
| Sensor input current | 1 mA (constant) |
| Temperature measuring range | -50 °C … 200 °C |
| Connection technology | 2, 3, 4-wire |
Output data
| Number of outputs | 1 |
|---|---|
| Configurable/programmable | Yes |
| Voltage output signal | 0 V … 10 V |
| 10 V … 0 V | |
| 0 V … 5 V | |
| 1 V … 5 V | |
| Current output signal | 0 mA … 20 mA |
| 4 mA … 20 mA | |
| 20 mA … 0 mA | |
| 20 mA … 4 mA | |
| Max. output voltage | approx. 12.5 V |
| Max. output current | 23 mA |
| Short-circuit current | approx. 10 mA |
| Load/output load voltage output | > 10 kΩ |
| Load/output load current output | < 500 Ω (at 20 mA) |
| Ripple | < 20 mVPP(at 500 Ω) |
| < 20 mVPP(at 10 kΩ) |
