Key Commercial Data
| Orderkey | 2902033 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 91 (C-5-2017) |
| GTIN | 4046356652056 |
| Weight per Piece (excluding packing) | 128.800 g |
| Custom tariff number | 85437090 |
| Country of origin | DE (Germany) |
Ambient conditions
| Ambient temperature (operation) | -40 °C … 70 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
Input data
| Configurable/programmable | Yes |
|---|---|
| Voltage input signal | 0 V … 10 V (via DIP switch) |
| 0 V … 12 V (can be set via software) | |
| Current input signal | 0 mA … 20 mA (via DIP switch) |
| 0 mA … 24 mA (can be set via software) | |
| max. input voltage | 12 V |
| Max. input current | 24 mA |
| Input resistance of voltage input | > 120 kΩ |
| Input resistance current input | approx. 50 Ω (+ 0.7 V for test diode) |
Switching output
| Output name | Relay output |
|---|---|
| Contact type | 1 PDT |
| Contact material | AgSnO2, hard gold-plated |
| Maximum switching voltage | 250 V AC |
| 240 V AC (UL) | |
| Limiting continuous current | 6 A |
| Min. switching current | 100 mA (12 V DC) |
| Mechanical service life | 2x 107cycles |
| Setting range of the response delay | 0 s … 10 s (can be set freely via software) |
| Internal hysteresis | can be set freely via software |
| Max. switching current | 6 A (for 250 V AC) |
