Key Commercial Data
| Orderkey | 2906877 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 93 (C-5-2017) |
| GTIN | 4055626131566 |
| Weight per Piece (excluding packing) | 120.500 g |
| Custom tariff number | 85437090 |
| Country of origin | DE (Germany) |
Ambient conditions
| Ambient temperature (operation) | -40 °C … 70 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
Input data
| Number of inputs | 1 |
|---|---|
| Available input sources | Resistance thermometers |
| Sensor types (RTD) that can be used | Pt, Ni, Cu sensors |
| Connection technology | 2, 3, 4-wire |
| Sensor input current | approx. 200 µA |
| Max. permissible overall conductor resistance | ≤ 25 Ω (Per line, RTD in 3- or 4-wire technology) |
| ≤ 50 Ω (Per line, RTD in 2-wire technology) | |
| Linear resistance measuring range | 0 Ω … 4000 Ω |
| Linear mV signal range | -500 mV … 500 mV |
| Available input sources | Thermocouples |
| Sensor types that can be used (TC) | B, E, J, K, N, R, S, T, L, U, A-1, A-2, A-3, M, L |
Switching output
| Output name | Switching output |
|---|---|
| Number of outputs | 2 |
| Contact type | 2 N/O contacts |
| Maximum switching voltage | 30 V DC |
| Max. switching current | 100 mA (30 V (≤ 50 °C)) |
| 70 mA (30 V (51 °C … 70 °C)) |
