Key Commercial Data
| Orderkey | 2902052 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 80 (C-5-2017) |
| GTIN | 4046356652094 |
| Weight per Piece (excluding packing) | 110.000 g |
| Custom tariff number | 85437090 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -40 °C … 70 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
Input data
| Configurable/programmable | Yes |
|---|---|
| Sensor types (RTD) that can be used | Pt, Ni, Cu sensors |
| Linear resistance measuring range | 0 Ω … 4000 Ω (Minimum measuring span: 10% of the selected measuring range) |
| Sensor input current | approx. 200 µA |
| Temperature measuring range | -200 °C … 850 °C (Range depends on sensor type, range can be set freely via software or in increments from -150°C to 850°C via DIP switches) |
| Connection technology | 2, 3, 4-wire |
Output data
| Number of outputs | 1 |
|---|---|
| Configurable/programmable | Yes |
| Voltage output signal | 0 V … 5 V (via DIP switch) |
| 1 V … 5 V (via DIP switch) | |
| 0 V … 10 V (via DIP switch) | |
| 10 V … 0 V (via DIP switch) | |
| 0 V … 10.5 V (can be set via software) | |
| Current output signal | 0 mA … 20 mA (via DIP switch) |
| 4 mA … 20 mA (via DIP switch) | |
| 20 mA … 0 mA (via DIP switch) | |
| 20 mA … 4 mA (via DIP switch) | |
| 0 mA … 21 mA (can be set via software) | |
| Max. output voltage | approx. 12.3 V |
| Max. output current | 24.6 mA |
| Short-circuit current | < 31.5 mA |
| Load/output load voltage output | ≥ 10 kΩ |
| Load/output load current output | ≤ 600 Ω (at 20 mA) |
| Ripple | < 10 mVrms |
| < 10 mVrms(at 600 Ω) |
