Key Commercial Data
| Orderkey | 2902004 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 90 (C-5-2017) |
| GTIN | 4046356651851 |
| Weight per Piece (excluding packing) | 106.200 g |
| Custom tariff number | 85437090 |
| Country of origin | DE (Germany) |
Ambient conditions
| Ambient temperature (operation) | -40 °C … 70 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
Power supply
| Nominal supply voltage | 24 V DC |
|---|---|
| Supply voltage range | 9.6 V DC … 30 V DC (The DIN rail bus connector (ME 6,2 TBUS-2 1,5/5-ST-3,81 GN, Order No. 2869728) can be used to bridge the supply voltage. It can be snapped onto a 35 mm DIN rail according to EN 60715)) |
| Typical current consumption | 18 mA (24 V DC) |
| 35 mA (12 V DC) | |
| Power consumption | 450 mW (9.6 V DC) |
Connection data
| Connection method | Screw connection |
|---|---|
| Single conductor/terminal point, solid, with ferrule, min. | 0.20 mm² |
| Single conductor/terminal point, solid, with ferrule, max. | 1.50 mm² |
| Single conductor/terminal point, solid, without ferrule, min. | 0.20 mm² |
| Single conductor/terminal point, solid, without ferrule, max. | 2.50 mm² |
| Conductor cross section flexible min. | 0.2 mm² |
| Conductor cross section flexible max. | 1.5 mm² |
| Min. AWG conductor cross section, flexible | 24 |
| Max. AWG conductor cross section, flexible | 12 |
| Stripping length | 10 mm |
| Screw thread | M3 |
