Key Commercial Data
| Orderkey | 2811103 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 236 (C-7-2013) |
| GTIN | 4017918125400 |
| Weight per Piece (excluding packing) | 204.500 g |
| Custom tariff number | 85437090 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -25 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C (non-condensing) |
| Maximum altitude | < 2000 m |
| Degree of protection | IP20 |
Input data
| Input voltage range | 0 V … 370 V AC |
|---|---|
| Input resistance | 370 kΩ |
| Input voltage range | 0 V … 250 V AC |
| Input resistance | 250 kΩ |
| Input voltage range | 0 V … 170 V AC |
| Input resistance | 170 kΩ |
| Input voltage range | 0 V … 120 V AC |
| Input resistance | 120 kΩ |
| Input voltage range | 0 V … 80 V AC |
| Input resistance | 80 kΩ |
| Input voltage range | 0 V … 54 V AC |
| Input resistance | 54 kΩ |
| Input voltage range | 0 V … 36 V AC |
| Input resistance | 36 kΩ |
| Input voltage range | 0 V … 24 V AC |
| Input resistance | 24 kΩ |
| Nom. voltage | 440 V (ungrounded) |
| 250 V (to earth) |
Output data
| Output name | Voltage output |
|---|---|
| Voltage output signal | 0 V … 10 V |
| Max. output voltage | 15 V |
| Load/output load voltage output | > 10 kΩ |
| Ripple | < 50 mVPP |
| Output name | Current output |
| Current output signal | 0 mA … 20 mA |
| 4 mA … 20 mA | |
| Max. output current | 30 mA |
| Load/output load current output | < 500 Ω |
| Ripple | < 50 mVPP |
