Key Commercial Data
| Orderkey | 2864464 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 249 (C-5-2017) |
| GTIN | 4017918904456 |
| Weight per Piece (excluding packing) | 139.200 g |
| Custom tariff number | 85389091 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -20 °C … 65 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C (non-condensing) |
| Maximum altitude | ≤ 2000 m |
Input data
| Input | Current measuring input |
|---|---|
| Input current range | 0 A AC … 16 A |
| Impulse form | Sine |
| Overload capacity | 2 x IN (continuous) |
| Nominal frequency fN | 50 Hz |
| 60 Hz | |
| Frequency measuring range | 45 Hz … 65 Hz |
Switching output
| Output name | Relay output |
|---|---|
| Contact type | 1 PDT |
| Contact material | AgSnO, hard gold-plated |
| Maximum switching voltage | 30 V AC |
| 36 V DC | |
| 250 V AC (when the gold layer is destroyed) | |
| Limiting continuous current | 50 mA (for gold layer, 30 V AC/ 36 V DC) |
| 2 A (in case of a destroyed gold layer, 250 V AC) | |
| Setting range of the response delay | typ. 0.1 s … 10 s (Adjustable using a potentiometer) |
