Key Commercial Data
| Orderkey | 2864587 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 195 (C-5-2017) |
| GTIN | 4017918907266 |
| Weight per Piece (excluding packing) | 104.300 g |
| Custom tariff number | 85437090 |
| Country of origin | DE (Germany) |
Input data
| Configurable/programmable | Yes, programmable |
|---|---|
| Sensor types (RTD) that can be used | Pt, Ni (100, 500, 1000); min. measurement range 10 K |
| Sensor types that can be used (TC) | B, C, D, E, J, K, L, N, R, S, T, U; min. measurement range 50 K/500 K |
| Connection technology | 2, 3, 4-wire |
| Input signal range | 10 Ω … 400 Ω (min. measurement range 10 Ω) |
| 10 Ω … 2000 Ω (min. measurement range 100 Ω) | |
| -10 mV … 100 mV (min. measurement range 5 mV) |
Output data
| Signal output | Current output |
|---|---|
| Configurable/programmable | Yes |
| Current output signal | 4 mA … 20 mA |
| 20 mA … 4 mA | |
| Max. current output signal | ≤ 23 mA |
| Output current with short-circuit | ≤ 3.6 mA or ≥ 21 mA (adjustable, not for thermocouples) |
| Output current with wire break | ≤ 3.6 mA or ≥ 21 mA (adjustable) |
| Output current range with overrange/underrange | 3.8 mA … 20.5 mA |
| Load/output load current output | ≤ 520 Ω (At UV= 24 V; Usupply– 12 V / 0.023 A) |
| Configurable/programmable | no |
Power supply
| Designation | Loop-powered |
|---|---|
| Supply voltage range | 12 V DC … 30 V DC |
| Max. current consumption | < 3.5 mA |
