Key Commercial Data
| Orderkey | 2814045 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 135 (C-7-2013) |
| GTIN | 4017918131708 |
| Weight per Piece (excluding packing) | 146.800 g |
| Custom tariff number | 85437090 |
| Country of origin | DE (Germany) |
Input data
| Description of the input | Current input |
|---|---|
| Number of inputs | 4 |
| Configurable/programmable | no |
| Current input signal | 0 mA … 20 mA |
| 4 mA … 20 mA | |
| max. input voltage | 30 V (30 V overload) |
| Max. input current | 50 mA (100 mA overload) |
| Response current | < 50 µA |
| Input voltage limitation | 33 V (with Zener diode) |
| Voltage dissipation | 2.5 V (I = 20 mA) |
Output data
| Output name | Current output |
|---|---|
| Number of outputs | 4 |
| Configurable/programmable | no |
| Current output signal | 0 mA … 20 mA |
| 4 mA … 20 mA | |
| Max. output current | < 50 mA |
| Load/output load current output | ≤ 1375 Ω (at I = 20 mA output signal) |
| Ripple | < 5 mV (rms) |
| Transmission Behavior | 1:1 to input signal |
