Key Commercial Data
| Orderkey | 2924320 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 130 (C-5-2017) |
| GTIN | 4046356503884 |
| Weight per Piece (excluding packing) | 139.000 g |
| Custom tariff number | 85437090 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -20 °C … 60 °C (Any mounting position) |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 80 °C |
| Maximum altitude | ≤ 2000 m |
| Permissible humidity (operation) | 5 % … 95 % (non-condensing) |
| Noise immunity | EN 61000-6-2 When being exposed to interference, there may be minimal deviations. |
Input data
| Sensor types (RTD) that can be used | Pt, Ni, Cu sensors: 2, 3, 4-wire |
|---|---|
| Temperature measuring range | -200 °C … 850 °C (Range depending on the sensor type) |
| Input signal range | 0 Ω … 2000 Ω |
| Cable resistance | 50 Ω per line |
| Sensor input current | 200 μA … 1 mA |
| Measuring range span | > 50 K |
Output data
| Signal output | Current output |
|---|---|
| Configurable/programmable | Yes |
| Current output signal | 0 mA … 20 mA |
| 4 mA … 20 mA | |
| Load/output load current output | ≤ 500 Ω |
| Output ripple (current) | < 50 µAPP |
| Behavior in the event of a sensor error | As per NE 43 or can be freely defined |
| Configurable/programmable | no |
