Key Commercial Data
| Orderkey | 2810612 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 246 (C-5-2017) |
| GTIN | 4046356153775 |
| Weight per Piece (excluding packing) | 172.500 g |
| Custom tariff number | 85437090 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -20 °C … 65 °C (-4 °F…149 °F) |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C (-40 °F … 185 °F) |
| Maximum altitude | 2000 m |
Input data
| Configurable/programmable | Via DIP switches |
|---|---|
| Input current range | 0 A … 5 A |
| Setting range for min. input current | 0 A AC … 1 A (configurable) |
| Setting range for max. input current | 0 A AC … 5 A (configurable) |
| Overload capacity | 2 x IN (continuous) |
| Surge strength | 20 x IN(1 s) |
| Nominal frequency fN | 50 Hz |
| Frequency measuring range | 45 Hz … 65 Hz |
| Connection method | Screw terminal block |
Output data
| Output name | Current output |
|---|---|
| Configurable/programmable | Via DIP switches |
| Current output signal | 0 mA … 20 mA (configurable) |
| 4 mA … 20 mA (configurable) | |
| Max. output current | 25 mA |
| Load/output load current output | < 500 Ω (20 mA) |
| Ripple | < 10 mVPP(for 500 Ω at 20 mA) |
| Status display | LED red (error), LED green (ready) |
