Key Commercial Data
| Orderkey | 2865586 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 146 (C-5-2017) |
| GTIN | 4046356160513 |
| Weight per Piece (excluding packing) | 176.100 g |
| Custom tariff number | 85437090 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -20 °C … 60 °C (Any mounting position) |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 80 °C |
| Maximum altitude | ≤ 2000 m |
| Permissible humidity (operation) | 5 % … 95 % (non-condensing) |
| Noise immunity | EN 61000-6-2 When being exposed to interference, there may be minimal deviations. |
Input data
| Input | Intrinsically safe |
|---|---|
| Sensor types that can be used (TC) | E, J, K, N as per IEC / EN 60584, L as per DIN 43760 |
| Temperature measuring range | -250 °C … 1372 °C (Range depending on the sensor type) |
| Input signal range | -20 mV … 70 mV |
| Measuring range span | Min. 50 K for thermocouples, 3 mV for mV sources |
Output data
| Signal output | Current output |
|---|---|
| Configurable/programmable | Yes |
| Current output signal | 0 mA … 20 mA |
| 4 mA … 20 mA | |
| Load/output load current output | ≤ 500 Ω |
| Output ripple (current) | < 50 µAPP |
| Behavior in the event of a sensor error | As per NE 43 or can be freely defined |
| Configurable/programmable | no |
