Key Commercial Data
Orderkey | 2924676 |
---|---|
Packing unit | 1 pc |
Catalog page | Page 142 (C-5-2017) |
GTIN | 4046356665483 |
Weight per Piece (excluding packing) | 163.800 g |
Custom tariff number | 85437090 |
Country of origin | DE (Germany) |
Note
Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
---|
Ambient conditions
Ambient temperature (operation) | -20 °C … 60 °C (Any mounting position) |
---|---|
Ambient temperature (storage/transport) | -40 °C … 80 °C |
Maximum altitude | ≤ 2000 m |
Permissible humidity (operation) | 10 % … 95 % (non-condensing) |
Noise immunity | EN 61000-6-2 When being exposed to interference, there may be minimal deviations. |
Input data
Signal input | Intrinsically safe |
---|---|
Current input signal | 4 mA … 20 mA |
Transmitter supply voltage | > 16 V (at 20 mA) |
Underload/overload signal range | 0 mA … 24 mA |
Output data
Signal output | Current output |
---|---|
Current output signal | 4 mA … 20 mA (active) |
Transmission Behavior | 1:1 to input signal |
Load/output load current output | ≤ 450 Ω (20 mA) |
≤ 375 Ω (24 mA) | |
Output behavior in the event of an error | < 3.6 mA (In the event of cable break at the input (as per NE 43)) |
> 22.5 mA (In the event of cable short circuit at the input (as per NE 43)) |
