Key Commercial Data
| Orderkey | 2908452 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| GTIN | 4055626446158 |
| Weight per Piece (excluding packing) | 42.900 g |
| Custom tariff number | 85437090 |
| Country of origin | US (United States) |
Ambient conditions
| Ambient temperature (operation) | -40 °C … 70 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
| Permissible humidity (operation) | 5 % … 95 % |
| Degree of protection | IP20 |
Power supply
| Nominal supply voltage | 24 V DC |
|---|---|
| Supply voltage range | 18 V DC … 30 V DC |
| Power consumption | ≤ 1600 mW (at IOUT= 20 mA, 24 V DC, 600 Ω load) |
Connection data
| Conductor cross section flexible min. | 0.2 mm² |
|---|---|
| Conductor cross section flexible max. | 1.5 mm² |
| Stripping length | 10 mm |
| Screw thread | M3 |
| Connection method | Screw connection |
General
| No. of channels | 1 |
|---|---|
| Maximum transmission error | < 0.1 % (of final value) |
| Maximum temperature coefficient | 0.01 %/K |
| Temperature coefficient, typical | 0.01 %/K |
| Limit frequency (3 dB) | 1.75 kHz (typ.) |
| Step response (10-90%) | < 200 µs (typ.) |
| Status display | Green LED (supply voltage) |
| Flammability rating according to UL 94 | V0 |
| Degree of pollution | 2 |
| Overvoltage category | II |
| Electromagnetic compatibility | Conformance with EMC directive |
| Color | gray |
