Key Commercial Data
| Orderkey | 2910154 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 556 (C-5-2017) |
| GTIN | 4055626447285 |
| Weight per Piece (excluding packing) | 0.000 g |
| Custom tariff number | 85364900 |
| Country of origin | US (United States) |
Ambient conditions
| Ambient temperature (operation) | -40 °C … 70 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 70 °C |
Coil side
| Nominal input voltage UN | 24 V DC |
|---|---|
| Input voltage range in reference to UN | 0.9 … 1.1 |
| Typical input current at UN | 13.5 mA |
| Typical response time | 5 ms |
| Typical release time | 8 ms |
| Protective circuit | Reverse polarity protection Polarity protection diode |
| Free-wheeling diode Damping diode | |
| Operating voltage display | Yellow LED |
Contact side
| Contact type | 1 PDT |
|---|---|
| Type of switch contact | Single contact |
| Contact material | AgSnO |
| Maximum switching voltage | 120 V AC |
| Min. switching current | 10 mA (at 12 V) |
| Maximum inrush current | on request |
| Limiting continuous current | 3 A (fuse limited) |
| Interrupting rating (ohmic load) max. | 23 W (at 110 V DC) |
| 360 VA (at 120 V AC) |
General
| Operating mode | 100% operating factor |
|---|---|
| Degree of protection | IP20 |
| Mechanical service life | 2x 107cycles |
| Mounting position | any |
| Assembly instructions | Plugs into VIP/…BASE… |
| Net weight (SAP) | 0 g |
