Key Commercial Data
| Orderkey | 2906598 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 554 (C-5-2017) |
| GTIN | 4055626171784 |
| Weight per Piece (excluding packing) | 53.200 g |
| Custom tariff number | 85369010 |
| Country of origin | US (United States) |
Ambient conditions
| Ambient temperature (operation) | -40 °C … 75 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 75 °C |
General
| Max. perm. operating voltage | 24 V DC |
|---|---|
| Max. operating voltage Umax | 30 V |
| Max. operating voltage | 30 V |
| Max. perm. current (per branch) | 1 A |
| Max. permissible current | 1 A |
| Number of positions | 1 |
| Status display | No |
| Mounting position | any |
| Degree of protection | IP20 |
Connection data for connection 1
| Connection name | Control circuits |
|---|---|
| Connection method | Pin strip |
| Number of connections | 1 |
| Number of positions | 13 |
Safety data
| Input voltage Ui | 30 V |
|---|---|
| Input current Ii | 1 A |
| Inductance Li | 0 mH |
| Capacitance Ci | 0 µF |
| Max. output voltage Uo | Ui |
| Max. output current Io | Ii |
| Max. output power Po | Pi |
| ATEX | Sira 16ATEX4260X; Ex II 3G Ex nA ic IIC T4 Gc; Ex nA IIC T4 Gc |
| IECEx | IECEx SIR 16.0088X Ex nA ic IIC T4 Gc; Ex nA IIC T4 Gc |
| FM approval | Class I, Zone 2, AEx nA ic IIC T4 Gc; AEx nA IIC T4 Gc Nonincendive: Class I, Div. 2, Groups A, B, C, D T4 With connection to Class I, II, and III, Div. 2, Groups A, B, C, D, E, F, G |
