Key Commercial Data
| Orderkey | 2703007 |
|---|---|
| Packing unit | 1 pc |
| GTIN | 4055626462950 |
| Weight per Piece (excluding packing) | 380.800 g |
| Custom tariff number | 85176200 |
| Country of origin | TW (Taiwan) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | 0 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
| Permissible humidity (operation) | 10 % … 95 % (non-condensing) |
| Altitude | 5000 m (For restrictions see manufacturer’s declaration) |
| 2000 m (With UL approval) | |
| Degree of protection | IP20 (Non-certificated by UL) |
General
| Electromagnetic compatibility | Conformance with EMC Directive 2014/30/EU |
|---|---|
| Mounting position | vertical |
| Net weight | 380.8 g |
| Housing material | Plastic |
| Color | gray |
| Conformance | CE-compliant |
| UL, USA/Canada | Class I, Div. 2, Groups A, B, C, D, T4 |
Power supply
| Nominal supply voltage | 24 V DC |
|---|---|
| 48 V DC | |
| Supply voltage range | 18 V DC … 57 V DC (Ordinary locations) |
| 24 V DC … 48 V DC (Hazardous locations) | |
| Max. current consumption | 4.2 A |
| 2.73 A (24 V DC) | |
| 1.34 A (48 V DC) | |
| Power consumption | ≤ 75 W |
| Protective circuit | Reverse polarity protection |
| Conductor cross section flexible max. | 4.00 mm² |
| Conductor cross section flexible min. | 0.75 mm² |
| Conductor cross section solid max. | 4.00 mm² |
| Conductor cross section solid min. | 0.75 mm² |
| Conductor cross section AWG max. | 12 |
| Conductor cross section AWG min. | 20 |
