Key Commercial Data
| Orderkey | 2403160 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 79 (C-6-2017) |
| GTIN | 4055626260587 |
| Weight per Piece (excluding packing) | 311.300 g |
| Custom tariff number | 85371091 |
| Country of origin | DE (Germany) |
Ambient conditions
| Degree of protection | IP20 |
|---|---|
| Ambient temperature (operation) | -25 °C … 55 °C |
| Ambient temperature (storage/transport) | -25 °C … 85 °C |
| Permissible humidity (operation) | 0 % … 75 % (according to DIN EN 61131-2, non-condensing, no ice formation) |
| Air pressure (operation) | 70 hPa … 106 kPa (up to 3000 m above sea level) |
| Air pressure (storage/transport) | 70 kPa … 106 kPa (up to 3000 m above sea level) |
| Resistance to gases that may endanger the functions, in acc. with DIN 40046-36, DIN 40046-37 | Sulfur dioxide (SO2) 10 ±0.3 ppm (test duration: 10 days), hydrogen sulfide (H2S) 1 ±0.3 ppm (test duration: 4 days), both at 25°C and with 75% humidity |
Control system
| Engineering tool | Niagara 4 |
|---|---|
| WorkPlace | |
| Programming languages supported | Niagara Framework® |
Data interfaces
| Interface | Ethernet |
|---|---|
| Number | 4 |
| Connection method | RJ45 socket, shielded |
| Transmission speed | 10/100 Mbps |
| Interface | RS-485 |
| Number | 2 |
| Connection method | Spring-cage connection |
| Transmission speed | max. 200 kbps |
| Interface | USB 1.0/USB 2.0 |
| Number | 1 |
| Connection method | USB type A, socket |
| Interface | USB OTG |
| Number | 1 |
| Connection method | Mini-USB |
| Interface | microSD |
| Number | 1 (Top) |
| Connection method | microSD slot |
| Protocols supported | BACnet/IP |
| BACnet MS/TP only at COM1 and COM2 | |
| Modbus/TCP | |
| Modbus/RTU | |
| KNX IP | |
| SNMP | |
| oBIX | |
| DALI | |
| and many more |
