Key Commercial Data
| Orderkey | 2702875 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 467 (C-6-2017) |
| GTIN | 4055626369846 |
| Weight per Piece (excluding packing) | 630.000 g |
| Custom tariff number | 85176200 |
| Country of origin | DE (Germany) |
Dimensions
| Dimensional drawing | |
|---|---|
| Width | 95 mm |
| Height | 123.4 mm |
| Depth | 57 mm |
| Note on dimensions | with connectors |
Ambient conditions
| Ambient temperature (operation) | -25 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -25 °C … 85 °C |
| Permissible humidity (operation) | 95 % (non-condensing) |
| Permissible humidity (storage/transport) | 95 % |
| Air pressure (operation) | 795 hPa … 1080 hPa (up to 2000 m above sea level) |
| Air pressure (storage/transport) | 66 kPa … 108 kPa (up to 3500 m above sea level) |
| Degree of protection | IP20 |
Wireless interface
| Wireless standard | Based on Bluetooth 4.0 |
|---|---|
| Modulation type | GFSK (Gaussian Frequency Shift Keying) |
| Antenna connection method | RSMA (female) |
| Frequency range | 2.402 GHz … 2.48 GHz (ISM bandwidth) |
| Transmission power | 5 dBm |
| Receiver sensitivity | -95 dBm |
Power supply for module electronics
| Connection method | Inline connector |
|---|---|
| Supply voltage | 24 V DC |
| Supply voltage range | 19.2 V DC … 30.5 V DC (via power connector) |
| Current consumption | 60 mA (at 24 V DC, at 25 °C) |
| Type of protection | Polarity protection, surge protection |
Digital inputs
| Input name | Digital inputs |
|---|---|
| Connection method | Spring-cage connection |
| Connection technology | 1-wire |
| Number of inputs | 16 |
| 16 | |
| Input voltage range “0” signal | < 5 V |
| Input voltage range “1” signal | > 15 V |
| Typical input current per channel | 2.3 mA |
