Key Commercial Data
| Orderkey | 2734170 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 237 (C-6-2017) |
| GTIN | 4017918819194 |
| Weight per Piece (excluding packing) | 810.000 g |
| Custom tariff number | 85176200 |
| Country of origin | DE (Germany) |
Dimensions
| Width | 179 mm |
|---|---|
| Height | 67 mm |
| Depth | 71 mm |
| Note on dimensions | With bus connectors and mounting plate |
Ambient conditions
| Ambient temperature (operation) | -20 °C … 55 °C |
|---|---|
| Ambient temperature (storage/transport) | -25 °C … 70 °C |
| Permissible humidity (operation) | 100 % |
| Permissible humidity (storage/transport) | 95 % (non-condensing) |
| Air pressure (operation) | 800 hPa … 1060 hPa (up to 2000 m above sea level) |
| Air pressure (storage/transport) | 700 hPa … 1060 hPa (up to 3000 m above sea level) |
| Degree of protection | IP65/IP67 |
| Note | Seal unused slots/connections to ensure the degree of protection. |
General
| Mounting type | Wall mounting |
|---|---|
| Net weight | 810 g |
| Note on weight specifications | without plug or mounting plate |
| Note | Seal unused slots/connections to ensure the degree of protection. |
Interfaces
| Designation | INTERBUS |
|---|---|
| Connection method | Optic fiber (polymer fiber 980/1000 µm) |
| Transmission speed | 500 kbps |
| Transmission physics | FO |
Power supply for module electronics
| Supply voltage | 24 V DC |
|---|---|
| Supply voltage range | 18.5 V DC … 32 V DC (including ripple) |
| Ripple | Max 3.6 VSSwithin the permissible voltage range |
| Supply current | typ. 120 mA |
