Key Commercial Data
| Orderkey | 2727365 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 187 (C-6-2017) |
| GTIN | 4017918168483 |
| Weight per Piece (excluding packing) | 550.000 g |
| Custom tariff number | 85389091 |
| Country of origin | DE (Germany) |
Ambient conditions
| Ambient temperature (operation) | -25 °C … 55 °C |
|---|---|
| Ambient temperature (storage/transport) | -25 °C … 85 °C |
| Permissible humidity (operation) | 10 % … 85 % (non-condensing) |
| Permissible humidity (storage/transport) | 10 % … 85 % (non-condensing) |
| Air pressure (operation) | 80 kPa … 106 kPa (up to 2000 m above sea level) |
| Air pressure (storage/transport) | 70 kPa … 106 kPa (up to 3000 m above sea level) |
| Degree of protection | IP20 |
| Note | Notes on operation Line protection for the network supply line, max. 20 A. Observe derating of the POWER-COMBICON connector |
Interfaces
| Designation | Inline local bus |
|---|---|
| No. of channels | 2 |
| Connection method | Inline data jumper |
| Transmission speed | 500 kbps |
| Transmission physics | Copper |
Mains connection
| Designation | Mains connection |
|---|---|
| Connection method | Power plug |
| Designation connection point | Terminal strip X11 and X12 |
| Number of positions | 5 |
| Permissible conductor cross section | max. 2.5 mm² (L1, L2, L3, N, PE (not leading)) |
| Operating voltage | 187 V AC … 500 V AC +0 % (conductor voltage) |
| Max. current carrying capacity | 20 A |
