Key Commercial Data
| Orderkey | 2985688 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 297 (C-6-2017) |
| GTIN | 4046356131582 |
| Weight per Piece (excluding packing) | 349.400 g |
| Custom tariff number | 85389091 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -25 °C … 55 °C |
|---|---|
| Ambient temperature (storage/transport) | -25 °C … 70 °C |
| Permissible humidity (operation) | 10 % … 85 % (Take suitable measures against increased air humidity within the permitted temperature range.) |
| Permissible humidity (storage/transport) | 10 % … 85 % (Take suitable measures against increased air humidity within the permitted temperature range.) |
| Air pressure (operation) | 80 kPa … 108 kPa (up to 2000 m above sea level) |
| Air pressure (storage/transport) | 66 kPa … 108 kPa (up to 3500 m above sea level) |
| Degree of protection | IP20 |
Interfaces
| Designation | Inline local bus |
|---|---|
| No. of channels | 2 |
| Connection method | Inline data jumper |
| Transmission speed | 500 kbps / 2 Mbps (can be switched) |
Digital inputs
| Input name | Digital inputs |
|---|---|
| Description of the input | IEC 61131-2 type 3 |
| Connection method | Spring-cage connection |
| Connection technology | 2, 3, 4-wire |
| Number of inputs | 4 (with two-channel assignment) |
| 8 (for single-channel assignment) | |
| Typical response time | See technical data |
| Input voltage | 24 V DC (via clock outputs UT1 and UT2 or external supply) |
| Input voltage range “0” signal | -3 V DC … 5 V DC |
| Input voltage range “1” signal | 11 V DC … 30 V DC |
| Input voltage range | -3 V DC … 30 V DC |
| Typical input current per channel | 4.2 mA (at 24 V) |
