Key Commercial Data
| Orderkey | 2700606 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 296 (C-6-2017) |
| GTIN | 4046356585859 |
| Weight per Piece (excluding packing) | 353.100 g |
| Custom tariff number | 85389091 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -25 °C … 55 °C |
|---|---|
| Ambient temperature (storage/transport) | -25 °C … 70 °C |
| Permissible humidity (operation) | 10 % … 85 % (Take suitable measures against increased air humidity within the permitted temperature range.) |
| Permissible humidity (storage/transport) | 10 % … 85 % (Take suitable measures against increased air humidity within the permitted temperature range.) |
| Air pressure (operation) | 80 kPa … 108 kPa (up to 2000 m above sea level) |
| Air pressure (storage/transport) | 66 kPa … 108 kPa (up to 3500 m above sea level) |
| Degree of protection | IP20 |
Interfaces
| Designation | Inline local bus |
|---|---|
| No. of channels | 2 |
| Connection method | Inline data jumper |
| Transmission speed | 500 kbps / 2 Mbps (can be switched) |
Digital outputs
| Output name | Digital outputs |
|---|---|
| Connection method | Spring-cage connection |
| Connection technology | 2, 3, 4-wire |
| Number of outputs | 4 (with two-channel assignment) |
| 8 | |
| Type of protection | Overload protection, short-circuit protection of outputs |
| Output voltage | 24 V DC (US– 1 V) |
| Nominal output voltage | 24 V DC |
| Output current | max. 6 A (Total current of all outputs, -25 °C … 50 °C) |
| max. 4 A (Total current of all outputs, >50 °C … 55 °C) | |
| Maximum output current per channel | 2 A |
| Maximum output current per group | 3 A |
| Nominal load, inductive | see safety data |
| Nominal load, lamp | see safety data |
| Nominal load, ohmic | see safety data |
