Key Commercial Data
| Orderkey | 2702233 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 521 (C-6-2017) |
| GTIN | 4055626067049 |
| Weight per Piece (excluding packing) | 216.900 g |
| Custom tariff number | 85176200 |
| Country of origin | DE (Germany) |
Ambient conditions
| Ambient temperature (operation) | -40 °C … 70 °C |
|---|---|
| -40 °F … 158 °F | |
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
| Degree of protection | IP20 |
General
| Test voltage data interface/power supply | 500 V AC |
|---|---|
| Electromagnetic compatibility | Conformance with EMC Directive 2004/108/EC |
| Mounting position | any |
| Assembly instructions | on standard DIN rail NS 35 in accordance with EN 60715 |
| Net weight | 216.9 g |
| Color | gray |
| MTBF | 292 Years (Siemens model SN29500, temperature 40°C, env. factor 1.5 and stress factor 50%) |
| Conformance | CE-compliant |
Power supply
| Supply voltage range | 19.2 V DC … 30 V DC |
|---|---|
| Max. current consumption | 63 mA (at 24 V DC) |
| Typical current consumption | 46 mA (at 24 V DC) |
Serial interface
| Interface 1 | Bus |
|---|---|
| Transmission length | ≤ 100 m |
| Output nominal voltage | 24 V DC |
| Maximum output current | 3.937 A (per station) |
| Interface 2 | Modbus/TCP, HART IP, PROFINET |
| Interface | Ethernet 10/100Base T |
| Connection method | RJ45 socket, auto negotiation and auto crossing |
| Protocols supported | Modbus/TCP, HART IP, PROFINET |
